Supported Firmware

  • GV3 8.11+ and everything newer
  • GV4 v2.xx  (Mode 1)

Mode 1 Maximums

D7212GV3

  • 4 Areas
  • 40 Points
  • 27 Outputs
  • 63 Skeds
  • 100* Users
  • 8 Keypads
  • 0 Doors

D7412GV3

  • 8 Areas
  • 75 Points
  • 67 Outputs
  • 63 Skeds
  • 100* Users
  • 16 Keypads
  • 2 Doors

D9412GV3

  • 32 Areas
  • 246 Points
  • 131 Outputs
  • 63 Skeds
  • 250* Users
  • 16 Keypads
  • 8 Doors

D7212GV4

  • 4 Areas
  • 40 Points
  • 27 Outputs
  • 63 Skeds
  • 100* Users
  • 8 Keypads
  • 0 Doors

D7412GV4

  • 8 Areas
  • 75 Points
  • 67 Outputs
  • 63 Skeds
  • 400* Users
  • 16 Keypads
  • 2 Doors

D9412GV4

  • 32 Areas
  • 246 Points
  • 131 Outputs
  • 63 Skeds
  • 1000* Users
  • 16 Keypads
  • 8 Doors

*User 0 is a service passcode. Listed values are effectively 1 through N-1 plus a service passcode.  Sub-Users are NOT supported with Mode 1. (e.g. D9412GV4 has users 1-999 plus a service passcode.)

Symphony AC Software Licensing:

Licensing for Symphony AC is based on number of doors.  With an Alarm Panel, the licensing is based on the number of readers/doors that the alarm panel can potentially support. The Bosch panels/controllers each support up to 8 readers/doors. Below is a table that can be used to determine which access license would be needed if every reader/door was enabled on the panel/controller:

  • 8 Doors = 1 Alarm Panel
  • 16 Doors = 2 Alarm Panels
  • 32 Doors = 4 Alarm Panels
  • 64 Doors = 8 Alarm Panels
  • 128 Doors = 16 Alarm Panels
  • 256 Doors = 32 Alarm Panels
  • 512 Doors = 64 Alarm Panels
  • 1024 Doors = 128 Alarm Panels
  • 2048 Doors = 256 Alarm Panels
